AC240SADK |
||
| Size: | 44*150*24 mm | |
| NW: | 600g | |
| Views: | 3143 | |
More Images:
- Description
- Technical Data
- Product Views
- Installation
A. Epoxy sealed
B. Vandal resistant
C. Die-cast Aluminum
D. Frequency: EM125KHz
E. 2-6 digits pins by programme
F. 12 digits backlight keypad
G. Operation Voltage: 12 - 24 VAC or VDC
H. 2 relays output NO / COM / NC and Speaker output.
I. Strike time: 0 to 99 seconds
J. Capacity: Zone1, 1000 codes or cards, or combined
Zone2, 10 codes or cards, or combined
K. 2 LED indicators: Green, Red
L. Operation temperature: -30 degree to 70 degree
M. Installation: Surface mounted
N. Cable length: 1 meter ---14-wire for stand-alone, 16-wire for network
O. Water-proof, Dust-proof: IP66
P. Colour: Silver
Q. Dimension: 44*150*24 mm
|
Material |
Alumnium alloy |
|
Working Temperature |
-30?~70? |
|
Waterproof rating |
IP66 |
|
RH |
=95% |
|
DC input |
12-24 VAC or VDC |
|
Standby current |
=30mA |
|
Working current |
=160mA |
|
Application card mode |
EM ID Card |
|
Dimension |
44*150*24 mm |
|
Effective distance |
5cm |
|
Capacity |
1010pcs |
